Anytone AT-708 Plus CB Radio 24.265-29.655MHz AM FM 27MHz Mobile Radio Station Communciator 8W 11 Meter Radio

Sale!

Anytone AT-708 Plus CB Radio 24.265-29.655MHz AM FM 27MHz Mobile Radio Station Communciator 8W 11 Meter Radio

Original price was: $177.13.Current price is: $127.51.

& Free Shipping

Anytone AT-708 Plus CB Radio 24.265-29.655MHz AM FM 27MHz Mobile Radio Station Communciator 8W 11 Meter Radio

HOW TO OPERATE WITH YOUR RADIO

1. Screw the microphone plug into the microphone jack.

2. Make sure your antenna is securely connected to the antenna connector.

3. Make sure the SQUELCH control is turned fully conterclockwise.

4. Turn on the unit and adjust the volume control.

5. Select your desired channel.

6. To transmit, press the PTT button and speak in a normal tone of voice.

7. To receive, release the PTT button.

SPECIFICATIONS

GENERAL
Modulation Mode AM/FM
Frequency Range 26.565-27.99125MHz
Frequency Tolerance ±5.0ppm
Input Voltage 13.2V DC ± 15%
Dimensions 140x195x37mm
Weight 656g
Operating Temperature Range -20℃ to +50℃
Current Drain
Transmit:3A MAX ; Receive:Squelched 0.3A ; VOL Max:0.7A
Antenna Connector
UHF, SO-239
RECEIVER
Sensitivity Less than 1uV for 10dB(S+N)/N
Adjacent Channel Rejection 60dB
IF Frequencies 1st 10.695MHz
2nd 455KHz
Automatic Gain Control(AGC) Less than 10dB change in audio
Output for inputs from 10 to 50000uV
Squelch less than 1uV
Audio Output Power 1Watts at 8Ω less than 10% distortion
Frequency Response 300-3000Hz
TRANSMITTER
Power Output 8 Watts FM/AM
Frequency Response 300-3000Hz
Modulated signal distortion inferior to 5%
Output Impedance 50 ohms

Weight 0.9 kg
Dimensions 400 × 400 × 180 cm
