50W Mini Power Amplifier 25-27Mhz BJ-200 Mini-size and High Power CB Amplifier
BaoJie BJ-200 CB Radio Power Amplifier 50W HF Amplifier 3-30 MHz AM/FM/SSB/CW Walkie Talkie CB Amplifier
Functions:
This model can be amplify 50 W for CB radio.
Turn on / off switch
automatic reception / switch transmission
reversing electrode protect
Specifications
■ Mini high power ham radio amplifiers BJ-200
■ Frequency range: 3-30MHz
■ Output power: 50W
■ Input Power: 3-5W
■ Input current: 8-11A
■ Turn on/off switch
■ Electrode reversal protect
■ Auto receive/transmit switch
■ Dimension:109*125*35mm
■ Weight: 450g
■ Frequency range: 3-30MHz
■ Output power: 50W
■ Input Power: 3-5W
■ Input current: 8-11A
■ Turn on/off switch
■ Electrode reversal protect
■ Auto receive/transmit switch
■ Dimension:109*125*35mm
■ Weight: 450g
| Frequency | 3-30MHz |
| Supply | 12-14 Vcc |
| Input energy/power | 8-11 A |
| Input power | 3-5 W |
| Input power SSB | 2-10 W |
| FM Output power | 50 W Max |
| AM Output power | 100 W pep Max |
| Output power SSB | 150 W pep Max |
| Mode | AM-FM-SSB-CW |
| Fuse | 12:00 AM |
| Output power level | 1 |
| Size | 109x125x35 mm |
| Weight | 450 gr. |
Package including
1 * BaoJie BJ-200 Power Amplifier
