ICOM IC-F16 IC-F26 Portable Professional Radio UHF VHF with audio encryption and scrambling

Sale!

ICOM IC-F16 IC-F26 Portable Professional Radio UHF VHF with audio encryption and scrambling

Original price was: $276.84.Current price is: $189.00.

& Free Shipping

ICOM IC-F16 VHF 5Watt IC-F26 UHF Portable Communication Radio F16 F26 Long Range Walkie Talkie with audio encryption and scrambling


Tough and Reliable Construction

The IC-F16 series is built around an aluminum die-cast chassis and covered with a tough polycarbonate casing. This radio is built to last. Its dual slide rail securely locks the battery to the radio. The belt clip is clamped between the radio and the battery, making it nearly impossible to knock loose.

Simple Operation

Having only 3 buttons, one volume and one channel knob, the IC-F16 series does not require special training to use. Positive button action for sure operation even when wearing gloves allows you to get down to the business of communicating without fuss.

Optional Board

The IC-F16 series has an expansion socket for adding an optional board. Voice scrambler, man down and DTMF decoder features are available, depending on the installed board.

Most Popular Signalings Built-in

Use the built-in 2-Tone, 5-Tone, CTCSS and DTCS capabilities as standard to set up your own talk groups and quiet stand-by when others are talking.

Long Use even in Extreme Cold

Supplied 2300 mAh (typ.) Li-ion battery pack, BP-232H has superior electrochemical characteristics even in extremely cold areas. It provides stable output for longer while having less voltage reduction at low temperatures.

Other Features

  • Wide frequency coverage in one version
  • Optional voice scrambler, UT-109 and UT-110
  • Optional DTMF decoder, UT-108
  • Optional man down unit, UT-124
  • Multiple 2-Tone, Multiple 5-Tone
  • Lithium-Ion battery standard
  • LED low battery alert
  • TOT function and lock out penalty timer
  • 2 step power saver
  • Normal and priority scan
  • 500mW loud and clear audio
  • Optional VOX headset for hands free operation
  • Embedded ESN (Electronic serial number)
  • MDC PTT ID and MDC emergency call functions are available (Transmit only)
  • Wide/narrow (25/12.5kHz) channel spacing capability,and more…

General

IC-F16 IC-F26
Frequency coverage
(Varies according to version)
136–174 MHz 400-470 MHz
Number of channels 16 channels
Channel spacing
(Varies according to version)
12.5/25kHz 12.5/25 kHz
Type of emission 16K0F3E, 8K50F3E
Current drain Tx High 1.5A 1.6A
Rx Stand-by 70mA
Max. audio 300mA
Dimensions
(projections not included; W×H×D)
53×120×42.4 mm
3 ⁄32× 4 23/32×1 7 ⁄16 in
Weight (approx.) 296g; 10.4oz (with BP-232H)

Transmitter

IC-F16 IC-F26
RF output power 5W 4W
Spurious emissions 80dB (typ.)
Frequency stability ±2.5ppm
Audio harmonic distortion 3% typical
40% deviation
FM Hum and Noise 46dB typ. (W)
40dB typ. (N)

Receiver

IC-F16 IC-F26
Sensitivity at 12dB SINAD 0.25μV (typ.)
Adjacent channel selectivity (W/N) 75/65dB (typ.)
Spurious response rejection 70dB (min.)
Intermodulation rejection 74dB (typ.)
AF output power
(at 5% distortion with an 8Ω load)
500mW (typ.)

Function Comparison and Internal Unit Options

IC-F16, IC-F26
Number of option slots 1
CTCSS/ DTCS encoder Available
decoder Available
2-Tone encoder Available
decoder Available
5-Tone encoder Available
decoder Available
DTMF autodial Available
DTMF decoder UT-108
Voice Scrambler Inversion
Non-rolling UT-109
(Version 01)
Rolling UT-110
(Version 01)
APCO P25 digital
AES encryption
DES encryption
6.25kHz digital
MPT 1327
MDC 1200 Available (Limited functions)
LTR™ trunking
PassPort
Man Down function UT-124
Intrinsically safe

Applicable U.S. Military Specifications

Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.

Standard MIL-810 F
Method, Proc.
Low Pressure Storage 500.4 I
Low Pressure Operation 500.4 II
High Temperature Storage 501.4 I
High Temperature Operation 501.4 II
Low Temperature Storage 502.4-3 I
Low Temperature Operation 502.4-3 II
Temperature Shock 503.4 I
Solar Radiation 505.4 I
Rain Blowing 506.4 I
Rain Drip 506.4 III
Humidity Induced 507.4
Salt Fog 509.4
Dust Blowing 510.4 I
Vibration 514.5 I
Shock Functional 516.5 I
Shock Transit Drop 516.5 IV

Also meets equivalent MIL-STD-810 -C, -D and -E.

All stated specifications are subject to change without notice or obligation.

Weight 0.9 kg
Dimensions 400 × 400 × 180 cm
