The FT-7900R provides 50 Watts of power on the 144 Mhz band, and 40 Watts on the 430 MHz,and is designed for simplicity of operation along with high performance in the receiver section.
The FT-7900R is ideal for the active Ham who has a need for simplex, repeater, or FM satellite operation on both bands, but without the complication of cross-band repeat capability, which is available on our FT-8800R and FT-8900R models.
NOAA Weather ALert (U.S. Version only)
A special memory bank on the FT-7900R allows instant recall of the ten NOAA Weather frequencies.What’s more, you can enable a special “Severe Weather Alert” feature that will sound an alarm when a NOAA station transmits the special alert tone during a severe weather alert broadcast.
Over 1000 Memory Channels
The FT-7900R’s incredible memory channel capacity includes registers for over 1000 channels,each capable of storing a 6-character Alpha-Numeric label. And the memories may be stored in any of the 20 available memory groups; a particular memory channel may also be stored in multiple groups, if desired.
WiRES™ Internet Linking Capability
The FT-7900R’s DTMF signaling capability includes provision for easy access to Yaesu’s WiRES™ (Wide-coverage Internet Repeater Enhancement System) Internet linking nodes, as well as other linking systems that require a DTMF string for access.
YSK-7900 Remote Mounting Kit (option)
Using the optional YSK-7900 Separation Kit, which contains both cabling and a bracket for the remote front panel, you can mount the FT-7900R’s front panel on the vehicle’s dash board, then stow the radio’s body under the seat or in some other convenient, out-of-the-way location. The cables are approximately 20 feet (6 m) in length.
One-Touch “Hyper Memory” Operation
Five front panel keys allow complete transceiver configuration status to be stored for convenient one-touch recall. So you can set up favorite frequencies in each operating band, including the receive-only bands, then recall them with a single touch of a button!
High Power Output
Boasting a big 50 Watts of power output on 144 MHz, and 40 Watts on 430 MHz, the FT-7900R also includes provision for three lower power levels, so you never have to use more power than you really need. The power level is stored in regular and Hyper Memory registers, too.
Wide Receiver Frequency Coverage
The FT-7900R provides receiver coverage from 108 to 520 MHz, and 700 to 999.99 MHz (cellular blocked), so you have available a wide range of monitoring excitement, including AM Aircraft, Public Safety,Government, Business, and, of course, Amateur communications. The synthesizer steps appropriate for the operating band are automatically selected, too!
Specifications
GENERAL | |||||
Frequency Range Receive: | 108-520 and 700-999 MHz (cellular blocked). | ||||
Frequency Range Transmit: | 137-174, 420-470 MHz | ||||
Frequency Steps: | 5/10/12.5/15/20/25/50/100 kHz | ||||
Operating Modes: | F3E, F2D, F2A | ||||
Antenna Impedance: | 50 Ohm, Unbalanced | ||||
Antenna Jack: | SO-239 [U.S.A. version] | ||||
Frequency Stability: | < +60°C) to (-20°C 140°F -4°F ppm ±5> | ||||
Supply Voltage: | DC 13.8V ±15%, Negative Ground | ||||
Current Consumption: | Receive Squelched – Less than 0.5 A | ||||
TX | HI | ||||
0 | 144 MHz | 8.5 A | |||
0 | 430 MHz | 8.0 A | |||
Operating Temperature Range: | -20°C to +60°C (-4°F to +140°F) | ||||
Case Size: | 5.5×1.6×6.6 inches (140x42x168 mm) | ||||
Weight: | Approx. 2.2 Lbs (1.0 kg) | ||||
0 | |||||
TRANSMITTER | RF Power Output: | 50/20/10/5 Watts (144 MHz) z) | |||
0 | 40/20/10/5 Watts (430 MHz) | ||||
Modulation Type: | Variable Reactance | ||||
Maximum Deviation: | ±5 kHz | ||||
Spurious Radiation: | -60 dB or better | ||||
Microphone Impedance: | 2 K Ohm | ||||
Data Jack Impedance: | 10 K Ohm | ||||
0 | |||||
RECEIVER | |||||
Double-Conversion Superheterodyne | |||||
Intermediate Frequencies: | 45.05 MHz & 450 kHz | ||||
Sensitivity (12dB SINAD): | <0.2uV uV | ||||
Selectivity: | 12 kHz/30 kHz (-6/-60 dB) | ||||
Squelch Sensitivity: | Better than 0.16uV | ||||
2W @ 8 Ohm @ 5% THD | |||||
AF Output Impedance: e: | 4-16 Ohm (Internal Speaker 8 Ohm) | ||||
Specifications are subject to change. |
|
|
|
