Sale!

Discounted Anytone AT-708 Vehicle CB Radio 2-Way Transceiver Ham Mobile Radio

$167.00 $109.00

GENERAL

Channels : 40 channel

Frequency Range : 24.265MHz-29.655MHz

Frequency Control : PLL

Operating Temperature Range : -10°/+55° C

Discounted Anytone AT-708 Vehicle CB Radio 2-Way Transceiver Ham Mobile Radio



FEATURES: Channels: A, B, C, D, E, F, G, H, I ,L Emergency call channel available (CH9) AM/FM mode Scan function

ASQ function EU/RU mode



TECHNICAL SPECIFICATIONS

GENERAL

Channels : 40 channel

Frequency Range : 24.265MHz-29.655MHz

Frequency Control : PLL

Operating Temperature Range : -10°/+55° C

DC input voltage : 13.2V DC ±15%

Size : 180 (L)x35 (H)x140 (P) mm

Weight : 0,850 kg

RECEIVER

Receiving system : dual conversion superheterodyne

Intermediate frequency : I° IF: 10.695 MHz • II° IF: 455 KHz

Sensitivity : 0.5μV for 20 dB SINAD

Audio output power @10% THD : 2.0 W @ 8 Ohm

Audio distortion : less than 8% @ 1 KHz

Image rejection : .65 dB

Adjacent channel rejection : 65 dB

Signal/Noise ratio : 45 dB

Current drain at stand/by : 250mA

TRANSMITTER

Output power(AM+FM) : 8W @ 13.2V DC

FM: 1,8 KHz ± 0,2 KHz

Frequency response : from 400 Hz to 2.5 KHz

Output impedance : RF 50 Ohm unbalanced

Signal/Noise Ratio : 40 dB MIN

Current drain : 1100mA (Power position with no modulation)

Output power(FM version) : 18W @ 13.2V DC

Modulation : AM: from 85% to 95%

Modulation : FM: 1,8 KHz ± 0,2 KHz



Package includes:

1× Anytone CB Radio

1× Microphone

1x Power cable

1 × User Manual











Weight 1.0 kg
Dimensions 280 × 170 × 80 cm
