Main Function:
GPS function(Optional)
1024 channels
IP67 Waterproof
Record
10 Watts Output Power
PC Programmed function Software online updating
VOX Chinese and English Voice Selection
Color LCD display
Text messages in digital mode
Digital Encryption function
Built-in CTCSS/DCS
BCLO
High & Low Power selction Talk around function
Complying with digital protocol ETSI TS 102 361-1,-2,3
Compatible with Mototrbo Tier I & II
Scanning Function Lone work
Analog wide/Narrow bandwidth selection
End-tone Elimination
Operate in both Digital & Analogue mode
Allows easily migrate from analog to digital
Provide clearer voice communications in digital mode throughout the coverage area
Emergency Alert
Key side setting
High-Low Power
MD-398 | |
General | |
Frequency Range | 400-470MHz |
Channel | 1000 |
Working voltage | 7.2v |
Working temperature | -30℃~+60℃ |
Storage temperature | -40℃~+85℃ |
Continuous working time | Analog:15hours Digital:25hours |
Battery capacity | 2800Mah |
Transmitter | |
Frequency Range | 400-470MHz |
Channel spacing | 12.5KHZ |
Frequency stability | +/-1.5ppm |
TX power | Low:1W High:10W |
FM noise | -40dB @ 12.5KHZ |
Spurious emission | <-36dB m @ 1GHZ,> -30dB m @ 1G |
Adjacent channel selectivity | -60dB @ 12.5KHZ |
FM modulation mode | 12.5KHZ:11 F 0 F 3 E |
4FSK digital modulation mode | 12.5KHZ(data only):7K60FX 12.5KHZ(data+voice):7K60FX |
Modulation limit | 2.5KHZ @ 12.5KHZ |
Audio response | +1dB~-3dB |
Rated audio distortion | ≤3% |
Digital protocol | ETSITS102361-1,-2,-3 |
Vocoder type | AMBE+2TM |
Receiver | |
Frequency Range | 400-470MHz |
Channel spacking | 12.5KHZ |
Frequency stability | +/-1.0ppm |
Analog sensibility | 0.35uV/-116dBm(20dB SINAD) 0.22 uV/-120dBm(Typical) |
Digital sensibility | 0.3 uV/-117.4dBm(BER 5%) 0.7 uV/-110dBm(BER 1%) |
Spurious response | TIA603C: 65dB ETSI: 65dB |
Adjacent channel selectivity | TIA603C: 60dB @ 12.5KHZ ETSI: 60dB @ 12.5KHZ |
Spurious response suppression | TIA603C: 70dB ETSI: 70dB |
Receiving spurious emissions | <-57dBm @ 1GHZ,> -47dBm @ |
Blocking | 84dB |
Rated audio power | 1W |
Audio response | +1dB~-3dB |
Rated audio distortion | ≤3% |
PACKAGE Contents:
1 x TYT MD-398 Digital Radio (GPS)
1 x 7.4V 2800mah Li-ion Battery Pack LB-75L
2 x SMA-Male Antenna
1 x Belt Clip
1 x ENG Manual
1 x Desktop Charger ( 110V ~ 250V ) with Correct Adapter for your Country
1 x Programming Cable & CD Software
1 x TYT Earpiece
